I think this might be the largest of all of the moonflowers produced! This is the original Martin Supermoon. The unit uses a common 24 volt, 250 watt EHJ lamp with a very large mirrored dish behind it. The mirror dish features an adjustable speed DC motor for slow to very fast beam rotation. Attached to the plate that holds the mirror dish assembly is another small DC motor with an off-balance weight attached to the shaft. This motor rotates at different speeds to make a ‘Shaking’ effect as the entire unit is mounted on springs. Located on the front of the unit is yet another Adjustable speed DC motor. This motor is used to rotate the color wheel at the front of the unit. The wheel has 5 colors & white (no color). All functions of this unit are controlled from the 19” rack mount controller which features dedicated speed adjustment knobs for all 3 DC motors and also has an audio input (1/4” Plug) for audio synchronization. Each motor also has a push button to make the specific motor either respond to music or bypass and be run manually. Essentially you can choose to have some motors running constantly or reacting to music. Unit made in
This is a site and forum dedicated to unique and vintage lighting, effects and controllers. We also repair, maintain, sell and broker classic lighting and DJ equipment. Brought to you by VNC Lighting / FK Productions. Your source for Nightclub and live design!
Follow us on Facebook
Vintage Nightclub Lighting Ebay Auctions
Contact Vintage Nightclub Lighting
To contact Vintage Nightclub Lighting Email firstname.lastname@example.org
Sunday, June 16, 2013
A very unique unit from PSL. This is the Dancer Scan unit. It features 2 X 120 volt, 500 watt EHA Pre-Focus lamps at the rear of the unit. The light goes through a small convex lens and then through a very slow constantly moving dichoric wheel with many vibrant colors. The light then goes through a larger set of convex lenses and onto 2 large moving mirror panels. The panels move separately making 2 large beams that move up and down. At the top of the unit there are 2 different constantly rotating mirrored dishes (1 with strips of glass and the other squares of glass). When the mirror moves completely flat the light hits the mirrors creating stunning beam effects. The unit can run by itself with onboard patterns triggered by a microphone or can be remotely controlled by a standard 0 - 10 volt analogue controller. Awesome unit made in Italy.
