Thursday, June 23, 2016

SEAR Moving Deltalight Units


Awesome units from SEAR!  These are the Moving (Waving) Deltalight units.  Each unit features a 40 volt, 150 watt Discolux lamp located in the center of the unit.  Wrapped around the lamp is a sound active color wheel that is triggered from an on-board microphone.  This produces shafts of colored light the emits from the 10 round lenses on the front of the unit.  Added to the colored changing beams of light is an added sweeping effect produced from the side motor.  There is a very cool linkage which connects the motor and head (Reference Pictures).  Built like a tank in Italy.






















Sunday, June 12, 2016

SLE Butterfly Units


Gigantic lighting units from SLE! These are the Butterfly units which feature 1 X 120 volt, 1000 watt linear lamp that is attached to a internal arm that rotates and swivels.  Located around the arm is a gigantic color wheel that takes up much of the unit.  Unfortunately these units need a dedicated controller and I do not have it.  Also one of the units has had the PCB removed and manually wired for operation.  I am looking for more of these units working or not and the controller as well.  Very rare units made in Germany.





















Saturday, June 11, 2016

Studio Due Duet 400 Unit



Classic from Studio Due - Although not 100% sure. Studio Due is what I was told it was from the place I purchased but if anyone can confirm it would be great.  The unit features a central 36 volt, 400 watt EVD high power halogen lamp for great light output.  Around the lamp is a gel color wheel that moves to the beat of the music.  The dual mirrored dishes (With X  and Y axis's) also move in tandem with the color wheel.  Sound active operation via the microphone on the rear and also 0 - 10 volt operation with connection with the 1/4" connector on the rear. Super high quality movement comes from Italian Micro Motors on this fixture.  Great unit produced in Italy!
